ASME B1.3 – Screw Thread Gaging Systems for Acceptability: Inch and Metric Screw Threads (UN UNR UNJ M and MJ)
View contents.
GENERAL
(a) This Standard presents screw thread gaging systemssuitable for determining the acceptability of UN UNR UNJ M and MJ screw threads on externally andinternally threaded products. It establishes the criteriafor screw thread acceptance when a gaging system isused.
(b) A screw thread gaging system comprises a list ofscrew thread characteristics that must be inspected/evaluated to establish the acceptability of the screwthreads on a threaded product and the gage(s) whichshall be used when inspecting/evaluating those characteristics.
(c) Federal Government Use. This Standard isapproved by the Department of Defense and federalagencies and is incorporated into FED-STD-H28/20 Screw Thread Standards for Federal Services Section20. The use of this Standard by the federal governmentis subject to all the requirements and limitations ofFED-STD-H28/20.
Product Details
- Published:
- 10/12/2007
- ISBN(s):
- 9780791830901
- ANSI:
- ANSI Approved
- Number of Pages:
- 20
- File Size:
- 1 file 180 KB
- Redline File Size:
- 2 files 1.1 MB
- Note:
- This product is unavailable in Ukraine Russia Belarus
